Evaluación de la fiabilidad de microprocesadores COTS mediante las infraestructuras de depuración On-Chip
##plugins.themes.bootstrap3.article.sidebar##
ISSN: 1680-8894
E-ISSN: 2219-6714
Sección
Artículos
Artículos
Esta obra está bajo licencia internacional Creative Commons Reconocimiento-NoComercial-SinObrasDerivadas 4.0.
##plugins.themes.bootstrap3.article.main##
Enviado:
Jun 6, 2017
Publicado: Jun 6, 2017
Publicado: Jun 6, 2017
Resumen
Este artículo presenta una herramienta de inyección de fallos y la metodología para la realización de campañas de inyección de Single-Event-Upsets (SEUs) en microprocesadores Commercial-off-the-shelf (COTS). Este método utiliza las ventajas que ofrecen las infraestructuras de depuración de los microprocesadores actuales, además del depurador estándar de GNU (GDB) para la ejecución y depuración de los programas de pruebas. Los experimentos desarrollados sobre microprocesadores reales, así como en las máquinas virtuales, demuestran la viabilidad y la flexibilidad de la propuesta como una solución de bajo costo para evaluar la fiabilidad de los microprocesadores COTS
Palabras clave
Commercial-off-the-shelf (COTS), depuración integrada en el chip, efectos de la radiación, fiabilidad de microprocesadores, inyección de fallos, errores lógicosDescargas
